This BDS Suspension BDS826FSR Snap Ring Coilover Leveling Kit for the Toyota Tundra is designed to build on the factory front suspension design, providing a performance upgrade with a level stance. This kit is meant to be a bolt on installation while it maintains the factory coil springs and top plate to be used in conjunction with snap ring coilover struts. Preset, fully assembled Fox 2.0 Performance series coilovers utilize a threaded body to allow for preload adjustment. Fox utlizes a 6061 T6 Aluminum body for better heat dispersion, along with an internal floating piston to eliminate oil aeration, proprietary internals, and a 5/8" hard chrome plated heat treated alloy shaft.

BDS's upper control arms improve suspension travel while providing superior strength and styling over the factory arms. Their arms are made out of 1.5" OD Heavy wall tubing, fully welded with integrated support gussets. Brake line mounting tabs are included on the arms as well as an indexed ball joint cup to corret ball joint positioning back to the neutral position at ride height. BDS arms come fully assembled with OE rubber bushings for the frame mounts and a high quality ball joint, providing smooth, quiet operation and better durability than arms that use heims and uniballs. Rear Fox 2.0 Performance IFP shocks pair perfectly with the 2.0 Performance Series IFP coilover struts.

Features and Benefits:

• Provides a 2" front lifted and leveled stance
• Includes Fox 2.0 Performance Series Snap Ring Coilovers
• Includes BDS Performance Upper Control Arms
• Includes Fox 2.0 Peformance rear shocks
• Allows for larger tire and wheel setup *minor trimming may be riequired*
  • 33x12.50 tires w/20x9 wheels and 5" back spacing
• Estimated install: 3-4 hours
• Made in the USA
